File:PV module layout.jpg
| Uploaded by | Cesardd |
|---|---|
| Upload date | 2023-08-09T23:50:13Z |
| MIME type | image/jpeg |
| Dimensions | 1823 × 1647 px |
| File size | 1.6 MB |
Summary
| Description |
English: Typical interconnection of standard photovoltaic modules. Left: single string of 36 cells in series. Right: two sub-matrices in parallel, with 60 half-cut cells in series each. |
| Date | |
| Source | Own work |
| Author | César Domínguez |
